ISM code 134 DTCs identifies a remote Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source on the Cummins ISM CM871 (2007-09) engine, and this five-page PDF documents SPN 974 / FMI 4/4 (PID P372) in full. It sets out the fault description, component location, shop-talk notes, and a step-by-step troubleshooting tree so a technician can confirm and clear the code with a diagnostic tool.
ISM code 134 DTCs document details
| Brand | Cummins |
| Model coverage | ISM CM871 (2007-09) and ISX CM871 (2007-09) |
| System / Group | DTCs / Remote Accelerator Pedal or Lever Position Sensor Circuit |
| PID / SPN / FMI | P372 / SPN 974 / FMI 4/4 |
| Warning lamp | Red |
| Source | TruckFaultCodes.com fault-code library (© 2017) |
| Pages | 6 |
| File size | 0.2 MB |
| Format / Language | PDF / English |
Fault description and meaning
The remote accelerator position sensor is a potentiometer attached to the remote accelerator lever. It varies its signal voltage to the ECM as the lever is depressed and released, low at 0 percent and high at full travel. This document is filed under fault code 134, remote Accelerator Pedal or Lever Position Sensor 1 Circuit – Voltage Below Normal or Shorted to Low Source. The condition raises a red warning lamp on the dash. Because the sensor shares supply and return wires in the engine harness with other sensors, the manual advises checking for multiple active faults before starting the 134 procedure.
Document table of contents
- Fault code information: PID P372, SPN 974, FMI 4/4, lamp red
- Description
- Component location
- Shop Talk
- Troubleshooting steps (harness, connector, and ECM checks)
- Circuit-repair verification and code clearing
Applicable truck models
This procedure applies to Cummins ISM CM871 (2007-09) engines. The identical fault code and remote accelerator pedal or lever position sensor circuit also appear in the parallel Cummins ISX CM871 (2007-09) listing. The troubleshooting steps inspect the remote accelerator pedal or lever position sensor circuit connector pins, verify the 4.75 to 5.25 VDC supply across the sensor, and confirm the fault goes inactive with a diagnostic tool after any repair. Cummins publishes the authoritative service data for these engines on its official website.
Who needs this ISM code 134 DTCs manual
Fleet technicians and workshop owners diagnosing remote accelerator pedal or lever position sensor circuit complaints on 2007-09 emissions-era Cummins engines need this sheet to work the fault methodically. It pairs with the wider Cummins ISM CM871 DTC set for full engine-harness coverage.
