Cummins ISM code 143 is the DiagTechPro reference page for this Cummins diagnostic fault code 143 document, a 1-page PDF sourced from TruckFaultCodes.com (Copyright 2017) that covers the engine oil pressure low warning. The engine oil pressure and engine temperature sensors are used by the electronic control module (ECM) to monitor the lubricating oil pressure. The ECM monitors the voltage on the signal pin and converts this to a pressure value. The oil pressure value is used by the ECM for the engine protection system. When the condition is detected the ECM logs the fault and turns on the amber warning lamp to alert the driver and technician.
Cummins ISM code 143 document details
| Brand | Cummins |
|---|---|
| Model coverage | ISM CM570 (1999-02) / DTCs; ISX CM570 (1999-02) / DTCs; Signature CM570 (1999-02) / DTCs |
| System / Group | ISM CM570 (1999-02) / DTCs |
| Fault identifier | Code 143 (PID P100, SPN 100, FMI 1) |
| Warning lamp | Amber |
| Source | TruckFaultCodes.com |
| Year / Revision | Copyright 2017 |
| Pages | 1 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- Circuit Description
- Component Location
- Troubleshooting Steps
- Repair verification and clearing fault codes
Applicable truck models
This document applies to Cummins ISM CM570 (1999-02) / DTCs; ISX CM570 (1999-02) / DTCs; Signature CM570 (1999-02) / DTCs electronic engines used in on-highway and vocational trucks. The engine oil pressure and engine temperature sensors are located on the cylinder block to the left of the fuel filter, behind the air compressor. See Section E for a detailed component location view. The troubleshooting section walks through connector and pin inspection, engine-harness resistance measurements and pin-to-pin continuity checks, and ends with a road test that confirms the code is inactive and all fault codes are cleared. Because the same procedure isolates the sensor, the harness and the ECM in turn, it prevents replacing parts that are still good. Verify engine calibration and coverage against the official Cummins engine support site before ordering parts.
