Cummins fault code 3572 is the official Cummins ISX11.9 CM2250 troubleshooting document for the aftertreatment diesel exhaust fluid pressure sensor circuit, reported as SPN 4334, FMI 4 (“Voltage Below Normal or Shorted to Low Source”) and lights the amber warning lamp. This 16-page PDF covers the circuit description, the conditions that set the code, and the guided troubleshooting sequence run with INSITE electronic service tool.
Official document details
| Brand | Cummins |
|---|---|
| Model coverage | ISX11.9 CM2250 (2010-12), also ISX12 CM2250 (2010-12) |
| System / group | Aftertreatment Diesel Exhaust Fluid Pressure Sensor — DTC diagnostics |
| Fault code | 3572 (SPN 4334, FMI 4) |
| Publication no. | 4021704, 4022178, 4022254, 4022257, 4022250, 2883445, 4022256, 4022255 |
| Year / revision | Last modified 11-Jun-2010 |
| Pages | 16 |
| File size | 0.2 MB |
| Format | |
| Language | English |
What Cummins fault code 3572 means
The aftertreatment diesel exhaust fluid controller provides a 5 volt supply and a ground to the aftertreatment diesel exhaust fluid pressure sensor. When the voltage below normal or shorted to low source condition is detected, SPN 4334 / FMI 4 is logged. The document explains the component location, when the diagnostic runs, and how the code is validated and cleared after a repair.
The manual lists the possible causes of this fault code:
- Signal wire shorted to ground
- Malfunctioning aftertreatment diesel exhaust fluid controller
- Malfunctioning aftertreatment diesel exhaust fluid controller harness
Document table of contents
- Circuit Description
- Component Location
- Conditions for Running the Diagnostics
- Conditions for Setting the Fault Codes
- Action Taken When the Fault Code is Active
- Conditions for Clearing the Fault Code
- Shop Talk
- Associated Procedures
- Troubleshooting Steps
- Guided troubleshooting steps with INSITE electronic service tool
Applicable truck models and engines
This procedure applies to Cummins ISX11.9 CM2250 (2010-12) engines and the related ISX12 CM2250 build, with equivalent aftertreatment procedures across the CM2250 family (ISB6.7, ISC8.3, ISL9, ISX15). The Associated Procedures table cites publication 2883445 for the ISX11.9 CM2250 application. Confirm the ECM calibration revision before condemning a part; see Cummins official engine support for calibration details.
