Cummins fault code 287 is documented on this DiagTechPro library page for Cummins ISM CM871 (2007-09) engines, where it flags a Sae J1939 Multiplexed Accelerator Pedal Or Lever Sensor System – Received Network Data In Error condition (PID P91, SPN 91, FMI 2/19, Red lamp). This 3-page PDF reproduces the manufacturer description, shop talk, component location and step-by-step troubleshooting so technicians can confirm and clear the code.
Cummins fault code 287 overview
Cummins defines this code as “SAE J1939 MULTIPLEXED ACCELERATOR PEDAL OR LEVER SENSOR SYSTEM – RECEIVED NETWORK DATA IN ERROR” on the SAE J1939 Multiplexed Accelerator Pedal or Lever Sensor. Normally, switches, accelerators, and other components are connected to the engine electronic control module (ECM) directly through individual wires. Multiplexing allows those same components to be hard wired to an original equipment manufacturer (OEM) VECU or transmission electronic control unit in the cab. Then component values and states from components (such as sensors, accelerators, and switches) can be transmitted from the OEM VECU to the Cummins engine ECM over the SAE J1939 datalink.
Shop talk notes: Verify the electronic control module (ECM) calibration is correct. If necessary, recalibrate the ECM. This fault can occur when the OEM VECU detects an error on the accelerator.
Official document details
| Brand | Cummins |
| Model coverage | Cummins ISM CM871 (2007-09); Cummins ISX CM871 (2007-09) |
| System / Group | SAE J1939 Multiplexed Accelerator Pedal or Lever Sensor — ISM CM871 fault codes |
| Fault code | 287 (SPN 91, FMI 2/19) |
| Source | TruckFaultCodes.com Cummins fault code reference (© 2017) |
| Pages | 3 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- Fault code identification (PID, SPN, FMI, lamp)
- Description
- Shop Talk
- Troubleshooting Steps
Applicable truck models and engines
This document applies to Cummins ISM CM871 (2007-09); Cummins ISX CM871 (2007-09) equipped diesel engines that log Fault Code 287. Always confirm engine calibration and use a Cummins diagnostic tool such as INSITE to read live data before starting repairs. Full specifications are published on the Cummins official website.
Who needs this Cummins fault code 287 manual
Heavy-duty truck technicians, fleet workshops and owner-operators diagnosing an electronic control module warning on ISM CM871 engines will use this sheet to verify the fault before parts are replaced.
The full PDF is available in the DiagTechPro manuals library; a free account is required to download.
