This Cummins fault 3313 document is a troubleshooting PDF for the aftertreatment diesel oxidation catalyst intake temperature sensor circuit. It explains Fault Code 3313, SPN 4765 FMI 4, where low signal voltage or a short to low source is detected at the catalyst intake sensor circuit.
Official Cummins fault 3313 document details
| Brand | Cummins |
|---|---|
| Model coverage | ISB6.7 CM2250; also lists ISC8.3 and ISL9 CM2250, ISX15 CM2250, GX CM2250, ISX11.9 CM2250, QSL9 CM2250, and QSB6.7 CM2250 in associated procedures |
| System/Group | ISB6.7 CM2250 (2010-12) / DTCs; Aftertreatment Diesel Oxidation Catalyst Intake Temperature Sensor Circuit |
| Publication no. | 4022254 for ISB6.7 CM2250 associated procedures |
| Year/Revision | Last Modified: 11-Jun-2010; troubleshooting revision shown as 07-Dec-2010 |
| Pages | 18 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- Overview
- Circuit Description
- Component Location
- Conditions for Running the Diagnostics
- Conditions for Setting the Fault Codes
- Action Taken When the Fault Code is Active
- Conditions for Clearing the Fault Code
- Shop Talk
- Associated Procedures
- Troubleshooting Steps
- Guided Step 1 – Check the fault codes.
- Guided Step 2 – Check the aftertreatment diesel oxidation catalyst intake temperature sensor and circuit.
- Guided Step 3 – Check the aftertreatment DPF temperature sensor interface module.
- Guided Step 4 – Check the ECM and OEM harness.
- Guided Step 5 – Check ECM calibration and clear fault codes.
Applicable truck models
This file applies to Cummins CM2250 engines and aftertreatment systems identified in the extract, with ISB6.7 CM2250 as the listed group and additional associated procedure coverage for ISC8.3 and ISL9 CM2250, ISX15 CM2250, GX CM2250, ISX11.9 CM2250, QSL9 CM2250, and QSB6.7 CM2250. The fault concerns the aftertreatment diesel oxidation catalyst intake temperature sensor located between the turbocharger outlet and the intake of the exhaust aftertreatment; the extract instructs users to refer to the OEM service manual for exact location details. See the manufacturer at Cummins official website.
Who needs this Cummins fault 3313 manual
Workshop technicians need this Cummins fault 3313 manual when active aftertreatment regeneration is disabled, DEF injection is disabled, EGR operation is affected, or engine torque reduction may follow extended operation with the fault active. It is useful for checking INSITE™ fault status, inspecting dirty or damaged pins, measuring resistance, checking for pin-to-pin or pin-to-ground shorts, evaluating the aftertreatment DPF temperature sensor interface module, and confirming ECM calibration.
The full PDF is available in the DiagTechPro manuals library, free account required to download.
