rail pressure sensor drift is the Detroit DD Series diagnostic trouble code for fuel rail pressure sensor – drift high, and this page documents its official fuel rail pressure sensor circuit troubleshooting sheet. The three-page sheet lists the monitored parameter, a 10-second typical duration and a 25% engine derate with MIL and CEL, then walks the sensor and Motor Control Module (MCM) harness checks.
rail pressure sensor drift document details
| Brand | Detroit |
| Model coverage | DD Series — DD13, DD15, DD16 |
| System / group | DD Series (EPA 2007-Current) / DTCs |
| SPN | 164 |
| FMI | 20 |
| Fault | Fuel Rail Pressure Sensor – Drift High |
| Emissions / revision | EPA07 — Copyright 2017 |
| Pages | 3 |
| File size | 0.3 MB |
| Format | |
| Language | English |
Document table of contents
- Description, duration and engine derate
- Fuel rail pressure sensor disconnection and inspection
- Harness voltage measurement (pins 1 and 3)
- MCM 120-pin connector resistance checks
- Sensor or MCM replacement decision
Troubleshooting steps summarised
The fuel rail pressure sensor is disconnected and inspected, the ignition is turned ON (key ON, engine OFF), and the voltage between pins 1 and 3 is measured for a 4.5 to 5.5 volt reading. The procedure then checks the supply and signal wiring to pins 102, 58 and 78 of the MCM 120-pin connector, confirms circuit resistance below 5 ohms and signal-to-supply resistance above 10K ohms, and re-tests before condemning the sensor or the MCM.
