The PACCAR MX P1022 diagnostic manual is a technical service document covering back pressure valve (BPV) actuator faults in 2013 PACCAR MX engines compliant with EPA 2013 emissions standards. Published by PACCAR, this 11-page guide provides mechanics and technicians with comprehensive troubleshooting procedures, electrical diagrams, and component specifications for diagnosing and resolving internal short circuit detection in BPV actuator systems.
This resource addresses the P1022 fault code, which indicates an internal short circuit has been detected within the BPV actuator (component L096). The manual covers the complete diagnostic workflow, from initial key-cycle verification through component testing with DAVIE diagnostic software.
Document details and specifications — PACCAR MX P1022
| Brand | PACCAR |
| Model coverage | MX Engines (EPA 2013) |
| System/Group | DTCs / Emissions Control |
| Publication number | P1022 |
| Year | 2013 |
| Pages | 11 |
| File size | 0.7 MB |
| Format | |
| Language | English |
Table of contents
- P1022 Fault Code Description and Information
- BPV Actuator Component Description and Operation
- Control System and Fail-Safe Positions
- System Effects and Functional Requirements
- Electrical Diagrams and Connector Specifications
- Technical Data and Component Specifications
- Wiring Check Procedures
- Possible Causes and Additional Information
- Diagnostic Step-by-Step Troubleshooting Tree
- Step 1: Key-Cycle Performance
- Step 2: BPV Valve Visual Inspection and Mechanical Checks
- Step 3: Component Substitution Testing
- Step 4: DTC Reset Procedures
- Verification Drive Cycle Instructions
Applies to these models
This PACCAR MX P1022 diagnostic manual applies to 2013 PACCAR MX heavy-duty truck engines equipped with electronically controlled back pressure valve actuators (L096) and PCI engine control units communicating via E-CAN. The manual covers vehicles utilizing EPA 2013 emissions-compliant powertrain configurations and is compatible with DAVIE diagnostic software for testing and monitoring. For additional technical support and PACCAR-certified resources, visit PACCAR official website.
Who needs this PACCAR MX P1022 diagnostic manual
Diesel engine mechanics, heavy-duty truck technicians, and workshop owners diagnosing PACCAR MX engine fault codes require this MX P1022 diagnostic manual for accurate troubleshooting. Service facilities equipped with DAVIE diagnostic interfaces and performing emissions control system repairs will find the step-by-step procedures and electrical schematics essential for efficient problem resolution.
The complete PDF is available in the DiagTechPro manuals library. A free account is required to download this technical resource.
