The PACCAR MX P1029 fault diagnostic manual is a technical reference document published by PACCAR for technicians servicing MX-series diesel engines. This 2013 EPA emission standard guide covers the BPV (bypass valve) position sensor fault, a critical drivetrain electrical diagnostic that appears in the comprehensive freeze frame data. The manual is part of PACCAR’s formal diagnostic service documentation for heavy-duty truck engine control systems.
Document details and specifications — PACCAR MX P1029
| Brand | PACCAR |
| Model coverage | MX Engines (EPA2013) |
| System/Group | DTCs / MX Engines |
| Publication number | P1029 |
| Year/Revision | 2013 |
| Pages | 1 |
| File size | 0.3 MB |
| Format | |
| Language | English |
Table of contents
- Code number P1029
- Fault code description: BPV Position sensor fault
- Fault code information: 1 trip MIL, 3 drive cycle recovery
- Readiness group – None
- Freeze frame type – Comprehensive
- Description of component(s)
- Location of component(s)
- Diagnostic condition
- Set condition of fault code
- Reset condition of fault code
- Electrical diagram(s)
- Technical data
- Possible causes
- Additional information
- Diagnostic Step-by-Step
- Verification Drive Cycle
Applies to these models
This PACCAR MX P1029 fault document applies to heavy-duty trucks equipped with PACCAR MX diesel engines compliant with 2013 EPA emission standards. The diagnostic guidance is specific to bypass valve position sensor circuits and their integration with engine management systems. For additional technical support and official PACCAR resources, visit PACCAR official.
Who needs this MX P1029 fault manual
Diesel mechanics, truck technicians, and workshop service managers who diagnose and repair PACCAR MX engine faults require this MX P1029 fault reference to identify bypass valve sensor electrical failures and execute proper diagnostic procedures. Engine control system specialists and fleet maintenance teams rely on this manual to reduce repair time and ensure accurate fault resolution.
The complete MX P1029 fault diagnostic manual is available in the DiagTechPro manuals library. A free account is required to access and download this technical PDF document.
