This document is the 2013 PACCAR MX Diagnostic Service Manual covering MX lambda sensor P1706, specifically fault code P1706 (Lambda response rate – Too high). Published by PACCAR for MX-series diesel engines certified to EPA 2013 standards, this 5-page manual provides technicians and workshop owners with complete diagnostic procedures for oxygen sensor circuit faults and lambda sensor malfunction detection.
The P1706 fault code indicates that the measured oxygen concentration in the exhaust differs too much from the expected value. This lambda sensor codes manual details the sensor’s role in determining air/fuel ratio, controlling emissions (NOx and smoke limits), and managing diesel particulate filter regeneration in PACCAR MX engines.
Document details and specifications — MX lambda sensor
| Brand | PACCAR |
| Model coverage | PACCAR MX Series trucks |
| System/Group | DTCs / MX Engines (EPA 2013) |
| Publication number | Not specified |
| Year/Revision | 2013 |
| Pages | 5 |
| File size | 0.5 MB |
| Format | |
| Language | English |
Table of contents
- P1706 code number and fault code description
- Fault code information (MIL trips, drive cycle recovery, readiness group)
- Component description: lambda sensor and air/fuel ratio measurement
- Sensor heater and heating control stages
- System effects (smoke limit, NOx emissions control, DPF regeneration)
- Diagnostic conditions and set/reset conditions
- Electrical diagrams and wiring harness connectors (D420, F834)
- Technical data: component and circuit checks
- Diagnostic step-by-step troubleshooting procedure
- Verification drive cycle for repair validation
