This lambda sensor heater P1137 diagnostic manual covers fault code P1137, which indicates an incorrect power supply to the lambda sensor heater element. Published by PACCAR in their 2013 MX Diagnostic Service Manual, this document provides mechanics and workshop technicians with complete troubleshooting procedures, electrical specifications, and step-by-step repair guidance for lambda sensor heater faults on EPA 2013–compliant MX engines.
The lambda sensor heater P1137 is a critical emissions control component that maintains sensor operating temperature at approximately 750°C [1382°F]. When the ECU detects heater power supply voltage below 9V for more than 5 seconds, fault code P1137 is triggered, affecting air/fuel ratio control, smoke limit management, NOx emissions regulation, and diesel particulate filter regeneration.
Document details and specifications — lambda sensor heater
| Brand | PACCAR |
| Model coverage | MX engines (EPA 2013) |
| System/Group | DTCs / MX Engines (EPA2013) |
| Publication number | P1137 |
| Year/Revision | 2013 |
| Pages | 6 |
| File size | 0.5 MB |
| Format | |
| Language | English |
Table of contents
- Fault code description and information (P1137)
- Component description – lambda sensor and heater element
- Air/fuel ratio and sensor heating control stages
- System effects – smoke limit, NOx emissions, DPF regeneration
- Diagnostic condition and fault code set/reset conditions
- Electrical diagrams – connectors D420.C and F834
- Technical data – component and circuit checks
- Possible causes and additional information
- Step-by-step diagnostic troubleshooting procedure
- Verification drive cycle test protocol
