The injector solenoid valve P1214 diagnostic manual is a technical reference document published by PACCAR for servicing 2013 EPA-compliant MX engine fault codes. This guide focuses on fault code P1214, which identifies a short circuit condition in the injector solenoid valve circuit for cylinder 6, specifically between ECU pins D420 A7 and A8. The document provides workshop technicians with the essential diagnostic framework needed to troubleshoot and resolve this electrical fault.
This 1-page service document is part of the 2013 PACCAR MX Diagnostic Service Manual and contains structured diagnostic procedures for isolating the injector solenoid valve P1214 short circuit condition. The fault code P1214 indicates a direct electrical short between two critical ECU control pins, requiring systematic electrical testing and component inspection to locate the root cause.
Document details and specifications — injector solenoid valve
| Brand | PACCAR |
| Model coverage | MX Engines (EPA 2013) |
| System/Group | DTCs / Engine Management |
| Publication number | P1214 |
| Year/Revision | 2013 |
| Pages | 1 |
| File size | 0.4 MB |
| Format | |
| Language | English |
Table of contents
- Fault code number P1214
- Fault code description – Injector Solenoid Valve Cylinder 6 short circuit
- Fault code information and Engine Support Center contact
- Description of component(s)
- Location of component(s)
- Diagnostic condition
- Set condition of fault code
- Reset condition of fault code
- Electrical diagram(s)
- Technical data
- Possible causes
- Additional information
- Diagnostic Step-by-Step procedures
- Verification Drive Cycle
