This MX injector fault P1230 document is the official 2013 Diagnostic Service Manual covering DTC P1230 and fuel injection system diagnostics for PACCAR MX engines meeting EPA 2013 emissions standards. Published by PACCAR, this 4-page technical guide provides mechanics and technicians with comprehensive electrical schematics, component specifications, and repair procedures for injector solenoid valve faults.
Document details and specifications — MX injector fault
| Brand | PACCAR |
| Model coverage | MX Engines |
| System/Group | DTCs / MX Engines (EPA2013) |
| Year/Revision | 2013 |
| Pages | 4 |
| File size | 0.4 MB |
| Format | |
| Language | English |
Table of contents
- P1230 Fault Code Description and Information
- Injector Solenoid Valve Component Description and Control Logic
- Injector Calibration Codes and Programming Requirements
- Diagnostic Conditions and Set/Reset Criteria
- Electrical Diagrams and Wiring Harness Connectors (D420, B460, B461)
- Injector Solenoid Valve Pinout Tables (Cylinders 1–6)
- Technical Data and Component Resistance Specifications
- Step-by-Step Diagnostic Troubleshooting Procedure (Steps 1–6)
- Verification and Drive Cycle Validation
Applies to these models
This MX injector fault P1230 manual applies to 2013 PACCAR MX-series diesel engines compliant with EPA 2013 emissions standards. It covers all six-cylinder configurations with fuel injection systems controlled by the PCI ECU (D420). Technicians should reference this guide when diagnosing P1230 short-circuit faults affecting injector solenoid valves in any cylinder position. For official engine specifications and technical updates, visit PACCAR official website.
Who needs this injector fault P1230 manual
Diesel truck mechanics, workshop owners, and technicians specializing in PACCAR MX engine diagnostics need this manual. It is essential for anyone troubleshooting fuel injection electrical faults, performing injector replacement, or reprogramming injector calibration codes using DAVIE diagnostic software on PACCAR MX-powered trucks.
The complete injector fault P1230 PDF is available in the DiagTechPro manuals library. A free account is required to download the full document.
Related manuals library
How to use the P1230 diagnostic procedure
Start with the fault-code conditions and identify which injector circuit is implicated before disconnecting the harness. Compare the D420 ECU, B460, and B461 connector diagrams with the pin tables, then check the injector solenoid valve resistance against the technical data in the manual. After any wiring or injector repair, confirm the calibration code, clear the diagnostic code with DAVIE, and perform the verification steps in the published sequence. This keeps the PACCAR MX engine diagnosis tied to the OEM procedure instead of replacing parts from the code alone.
