This 9-page PDF is a CAT C15 timing calibration troubleshooting guide for the C15 On-Highway Truck Engine (MXS configuration). It covers diagnostic code 0022-13 “Engine Speed Signal Calibration Not Performed” and provides the complete Engine Speed/Timing Sensor calibration procedure using Caterpillar Electronic Technician (Cat ET) software.
Official CAT C15 timing calibration document details
| Brand | Caterpillar (CAT) |
| Model coverage | C15 Truck Engine MXS (C15 On-Highway MXS00001-UP) |
| System/Group | Engine Speed/Timing Sensor Calibration — DTCs 22-13, 261-13, 261-11 |
| Publication no. | RENR5088-10 |
| Year/Revision | Published 01/02/2009, Updated 25/02/2009 |
| Pages | 9 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- 0022-13 Engine Speed Signal Calibration Not Performed (PID 0022 FMI 13) — Conditions, System Response, Performance Effects
- Engine Speed/Timing Sensor — Calibrate (System Operation Description)
- Diagnostic Codes Table (22-13, 261-13, 261-11)
- Required Special Tools (7X-1171 Transducer Adapter, 6V-2197 Transducer, 7X-1695 Cable As, 170-3519 Harness)
- Test Step 1: Install the Transducer Adapter — Crankshaft Rotation Table (C7 through C18)
- Test Step 2: Install the Transducer
- Test Step 3: Connect the 7X-1695 Cable As (ADEM III and ADEM IV ECM wiring)
- Test Step 4: Start the Engine and Check for Diagnostic Codes
- Test Step 5: Calibrate the Engine Speed/Timing Sensor via Cat ET
- Post-Calibration Cleanup and Return to Service
Applicable truck models
This document applies to the Caterpillar C15 On-Highway Truck Engine, configuration MXS00001-UP. The crankshaft rotation table within the procedure also references models C7, C-9, C-10, C11, C-12, C13, C-15, C15, C-16, and C18, with engine-specific rotation degrees and calibration port locations. The C15 requires 60 degrees of crankshaft rotation in the opposite normal direction, with the timing calibration port located on counterweight 2 on the left side of the engine block. The procedure covers both ADEM III and ADEM IV Electronic Control Modules. For official Caterpillar parts and service information, visit Caterpillar Support.
Who needs this CAT C15 timing calibration manual
Diesel mechanics and workshop owners working on CAT C15 on-highway engines need this document when diagnostic code 22-13 is active — indicating that a timing calibration has never been performed on a new ECM, or after repairs to the front gear train, camshaft, or crankshaft. The guide is essential for anyone replacing an ECM or diagnosing rough running and white exhaust smoke tied to default timing operation.
