This 8-page PDF is a CAT C15 idle shutdown troubleshooting guide for the on-highway C15 truck engine (MXS configuration). It documents diagnostic code 0071-01 (PID 0071 FMI 01), the idle shutdown timer system operation, and step-by-step test procedures for verifying timer activation, driver alert functions, and override functions using Caterpillar Electronic Technician (Cat ET).
Official CAT C15 idle shutdown document details
| Brand | Caterpillar (CAT) |
| Model coverage | C15 Truck Engine MXS (C15 On-Highway Truck MXS00001-UP) |
| System / Group | Idle Shutdown Timer — SMCS 1901-038 — DTC 0071-01 (PID 0071 FMI 01) |
| Publication no. | RENR5088-10 |
| Year / Revision | Published 01/02/2009, updated 25/02/2009 |
| Pages | 8 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- 0071-01 Idle Shutdown (47) — Conditions Which Generate This Code, System Response, Possible Performance Effect
- Idle Shutdown Timer – Test — System Operation Description
- Test Step 1: Verify Activation of the Idle Shutdown Timer (Cat ET configuration screen, idle shutdown status verification)
- Test Step 2: Verify the Driver Alert Function for Idle Shutdown and the Override Function for Idle Shutdown (check engine lamp, clutch and brake override)
- Test Step 3: Check the State of the Related Conditions when the Vehicle is Parked (vehicle speed, cold mode, PTO switch, low idle verification)
Applicable truck models
This document applies exclusively to the Caterpillar C15 on-highway truck engine in the MXS configuration (serial numbers MXS00001-UP). The DTC 0071-01 is generated when the idle shutdown timer expires with coolant temperature above 38 °C (100 °F) and vehicle speed at zero. The guide also references related circuits including the check engine lamp circuit, service brake pedal position switch circuit, clutch pedal position switch circuit, vehicle speed and speedometer circuit, and PTO switch circuit. The idle shutdown timer is a customer-specified parameter programmable from 1 to 1440 minutes. If diagnostic code 84-08 (vehicle speed signal out of range) is active, the timer will not operate. For official Caterpillar product support, visit Caterpillar Support.
Who needs this CAT C15 idle shutdown manual
Diesel mechanics and fleet workshop owners troubleshooting unexpected engine shutdowns at idle on C15 MXS-series trucks need this document. It is essential for anyone diagnosing DTC 0071-01, verifying idle shutdown timer programming via Cat ET, or testing the driver alert and override functions.
