This is the official 2013 PACCAR MX engine P1091 diagnostic and troubleshooting manual published by PACCAR for technicians and workshop owners. The document covers fault code P1091 (Engine rail pressure control – Data erratic, intermittent, or incorrect) specific to PACCAR MX diesel engines compliant with 2013 EPA emissions standards. It provides technical data, electrical diagrams, set and reset conditions, and a step-by-step diagnostic procedure for identifying and repairing common rail pressure system faults.
Document details and specifications — PACCAR MX engine
| Brand | PACCAR |
| Model coverage | PACCAR MX Engines (2013 EPA) |
| System/Group | DTCs / Fuel System (Common Rail) |
| Publication no. | P1091 |
| Year/Revision | 2013 |
| Pages | 4 |
| File size | 0.5 MB |
| Format | |
| Language | English |
Table of contents
- Fault code P1091 description and information
- Component description (rail pressure sensor, common rail)
- System effect and feedback control
- Diagnostic condition and run criteria
- Set and reset conditions
- Electrical diagrams and wiring harness connectors (D420, F854)
- Technical data and component/wiring check procedures
- Possible causes and additional information
- Step-by-step diagnostic troubleshooting (Steps 1–4)
- Verification drive cycle procedure
Applies to these models
This P1091 DTC manual applies to all PACCAR MX diesel engines manufactured to 2013 EPA emissions standards. The fuel system diagnostic covers the common rail pressure sensor (component F854), PCI ECU (D420), and high-pressure rail release valve (L094) used in PACCAR medium and heavy-duty trucks. For additional technical support and engine specifications, visit PACCAR official.
Who needs this PACCAR MX engine P1091 manual
Diesel truck mechanics, workshop owners, and technicians specializing in PACCAR engine diagnostics need this manual to diagnose and repair common rail pressure control faults on 2013 EPA MX engines. The document is essential for anyone using DAVIE diagnostic software and performing high-pressure fuel system troubleshooting on PACCAR trucks.
The full MX engine P1091 diagnostic manual is available in the DiagTechPro manuals library. Free account registration is required to download the PDF.
