SPN 3517 FMI 19 is documented in this Detroit DD Series fault code reference PDF, which covers the DEF Tank Signal Erratic via CAN condition on Detroit engines. The 2-page document lists the fault description, the step-by-step troubleshooting sequence and the connector measurements a technician uses to confirm the repair.
Official document details
| Brand | Detroit |
|---|---|
| Model coverage | Detroit DD Series (EPA 2007-Current) GHG14 engines using the ACM2.1 |
| System / group | DD Series (EPA 2007-Current) / DTCs |
| Diagnostic code | FMI 19 / SPN 3517 |
| Year / revision | Source dated 2017 |
| Pages | 2 |
| File size | 0.2 MB |
| Format | |
| Language | English |
Document table of contents
- Fault code identification: SPN 3517, FMI 19
- DEF tank signal erratic via CAN
- ACM2.1 reprogramming verification
- DEF tank header harness resistance checks
- ACM2.1 terminating resistor measurement
- Harness repair and header replacement
Applicable truck models and engines
This fault code applies to Detroit DD Series (EPA 2007-Current) GHG14 engines using the ACM2.1, and the DiagTechPro library also files it under the Series 60 (DDEC VI, EPA 2007) DTC set. The diagnostic references the Aftertreatment Control Module (ACM2.1) used on these Detroit powertrains. See the manufacturer’s Detroit official website for current engine specifications and dealer support.
SPN 3517 FMI 19 troubleshooting overview
The sequence begins by asking whether the ACM2.1 was recently reprogrammed, then powers the modules down for five minutes before rechecking active faults. The Diesel Exhaust Fluid (DEF) tank header harness is measured across pins 1 and 2, with separate branches for readings above 80 ohms and 40 to 80 ohms. The ACM2.1 120-pin connector internal terminating resistor is checked across pins 48 and 49, and resistance to engine ground is verified to isolate a shorted DEF CAN harness, a failed ACM2.1 or a faulty DEF tank header.
